Lockt

Endpoint	Method	Description	Date
ALL	ALL	July release 1.1.0 baseline.	2022-07-01
/about	GET	Displays current release notes.	2022-07-10
/cedentialsummary	GET	List summary of credentials claimed and unclaimed.	2022-07-10
/doorstate	GET	List door battery levels.	2022-07-10
/location	GET	Get list of locations.	2022-07-10
/location	POST	Create locations.	2022-07-10
/object?listtypes	GET	Displays available object types.	2022-07-10
/object?type	GET	Displays object information using the provided object type.	2022-07-10
/acesslevel	DELETE	Delete access level.	2022-07-15
/credential?id	GET	Retreive credential by id.	2022-07-15
/credential?card_num	GET	Retreive credential by card_num.	2022-07-15
/ping	GET	Simple ping response to check connectivity and authorization.	2022-08-12
/settings	GET	Retrieve api settings.	2022-08-12
/site	GET	Retrieve basic site information.	2022-08-12
/user	PUT	Update user objects using only specified object properties.	2022-08-12
/user	POST	Bug fix for user update and delete requests.	2022-08-18
/fob	PUT	Reassign credentials tagged as FOBs to a different user, and update expiration date..	2022-08-18
/doors?user_id	GET	Retrieves list of doors based on user_id.	2022-08-31
/user	POST	Performance improvements for single record operations. Reduces time needed to execute changes on single records.	2022-09-06
/doors?id_num	GET	Retrieves list of doors based on user id_num.	2022-09-08
/delegate	GET	Retrieves list of access levels tagged as delegate roles.	2022-09-08
/delegate?purge	POST	Purges expired delegate access levels.	2022-09-08
/delegate	POST	Creates delegate access level based on supplied door_id and assigns to supplied user_id.	2022-09-08
/credential	GET	Addition of access_expires and access_effective to all credential GET endpoints.	2022-11-11
/credential	PUT	New endpoint for direct management of credential data.	2022-11-11
/unlock	POST	New endpoint to provide momentary unlock capability for hard-wired doors.	2022-11-11
/time	GET	Utility to assist with management of time data.	2022-11-11

Version	URL reference
Version 1.1.0	v1

Status Code	Description
200	The request was processed successfully
400	There was an error processing your request. Details will be supplied in the response body.
401	Access to the indicated resource was denied. Details will be provided in the response body.
404	The resource was not found.
50X	An unexpected error has occurred.

Message	Description
No data found or invalid JSON objects supplied. Could not parse input.	The body of the request contained no data, or contained incorrectly structured data.
Batch size exceeds maximum of X objects.	The supplied payload exceeds the currently allowed number of objects per batch.
Validation errors found. Batch has failed. Details provided.	Some objects have failed validation. Details will be provided in the response body.
Unable to enumerate dependant record. Batch has been terminated and exception flagged.	A communications error has occurred with your instance of Lockt SecureAccess.
Unable to locate template. Batch has been terminated and exception flagged.	A communications error has occurred with your instance of Lockt SecureAccess.
The destination host is unreachable.	A communications error has occurred with your instance of Lockt SecureAccess.
An Unexpected Error has occurred. Request has been terminated and exception flagged.	A communications or processing error has occurred with your instance of Lockt SecureAccess.

Restriction	Description
POST Operation Record Limit	POST Operations are currently limited by default to 100 records per call. This may change per customer instance. Processing larger batches of records requires paging and processing in blocks of the allotted maximum size.
POST Operation Rate Limit	Rate limiting is currently being implemented to prevent simultaneous and overlapping POST operations.

All response calls to the API will return in a standard format as indicated below.

GET Requests (Read)

Node	Description
data	The body of the response return as an array of response objects.
errors	Any processing or validation errors will appear in the data node, returned as an array of error objects.

Response Format

#Standard Response
{
    "data": {
        [array of response objects]
    }
}

#Error Response
{
    "data": {
        {"error":"error message"}
    }
}

POST Requests (Write)

Node	Description
process summary	The number of records submitted, processed, and errors.
errors	Any processing or validation errors will appear in the errors node of the data object.

Response Format


                                            #Result if the process succeeds and no errors
{
    "data": {
        "submitted": number of records submitted,
        "inserted": number of records inserted,
        "updated": number of records updated,
        "errors": number of errors encountered
    }
}

#Result if errors are encountered
{
    "result": [Array of text messages indicating what caused the problem],
    "errors": [Array of error objects that indicate what specifically occurred]
}

#Example errors encountered updating users
{
    "error": [
        "Non-Numeric card_num found: A8914",
        "Invalid email address found: rgreswell0@@@@gravatar.com"
    ],
    "input_data": {
        "id": -1,
        "id_num": "qjwi-880329359",
        "first_name": "Rhea",
        "last_name": "Greswell",
        "card_num": "A8914",
        "email": "rgreswell0@@@@gravatar.com",
        "phone": "8184365134",
        "access_effective": "2022-01-24 00:00:00",
        "access_expires": "2022-10-29 00:00:00",
        "pin": "0986",
        "enabled": false,
        "accesslevels": [
            {
                "id": 574
            }
        ]
    }
}

Entity Model

Domain Model

Relationships

Object	Description
User	Users represent individual credential holders in Lockt SecureAccess. User objects contain basic information such as name, id_num, email and phone. User objects also reference other objects such as access levels and credentials. Users can be assigned to multiple access levels and can hold multiple credentials.
Fobs	Fobs are special derivatives of user records that are used specifically for the purpose of managing fob devices. Like users, fob objects also reference other objects such as access levels and credentials. Fobs can be assigned to multiple access levels and can hold multiple credentials
Credential	Credentials represent digital access keys and are used to uniquely identify a user in the Best Switch Mobile app. Users can hold multiple credentials. But, credentials can only be held by one user.
Access Levels	Access Levels represent logical groups of doors that are tied to schedules. Access Levels are similar to security groups as they combine a collection of doors that, when assigned to a user, grant the user access to the door on the indicated schedule.
Doors	Doors are individual openings over which the system governs access. Multiple doors can be assigned to access levels. Likewise, multiple access levels can reference the same door.
Schedules	Schedules represent a collection of individual days and start / stop times. Schedules are applied to access levels and are used to determine which days and times to grant access to a door, via an access level.
Events	Events are representations of actions that have occurred within the system. Events reference numerous objects, including several objects that are not callable through the API.

The following endpoints are available for use. Details on request and response specifics can be found in the subsequent sections.

Functional Endpoints: 44
System Endpoints and Utilities: 9
Total Endpoints: 53

Functional Endpoints

Endpoint	Method	Purpose	Comments	Status
/accesslevel	DELETE	Delete specified access levels.		Released
/accesslevel	GET	List all access levels in the system.		Released
/accesslevel?name=[name]	GET	Retrieve access level with indicated name.		Released
/accesslevel	POST	Creae access levels by assigning doors to schedules.		Released
/credential	DELETE	Delete indicated credential.		Released
/credential?user_id=[user_id]	GET	List all credentials in the system, for the indicated user.		Released
/credential	GET	List all credentials in the system.		Released
/credential?card_num=[card_num]	GET	Retrieve access level with indicated card_num.		Released
/credential?id=[id]	GET	Retrieve access level with indicated id.		Released
/credential	PUT	Update limited number of fields on a credential directly.		Released
/credentialsummary	GET	List summary of credentials claimed and unclaimed.		Released
/delegate	GET	List access levels used for delegation.		Released
/delegate	POST	Create and assign new delegate access.		Released
/delegate?purge=[purge]	POST	Delete all expired delegate access levels (where access_expires < current date/time).		Released
/door	DELETE	Remove door records.		Released
/door?id_num=[id_num]	GET	List all access-controlled doors assigned to the specified id_num across all assigned access levels.		Released
/door?user_id=[user_id]	GET	List all access-controlled doors assigned to the specified user_id across all assigned access levels.		Released
/door	GET	List all access-controlled doors in the system.		Released
/door	POST	Create access-controlled doors in the system.		Released
/doorstate	GET	List door battery levels.		Released
/events	GET	Return maximum number of locally cached events in the system (default 5000).		Released
/events?id=[id]	GET	Return most recent events starting with the last event id.	id represents the sequential Lockt SecureAccess event internal id.	Released
/fob	DELETE	Remove fob records.		Released
/fob?card_num=[card_num]	GET	Get individual Fob by card_num.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/fob?id_num=[id_num]	GET	Get individual Fob by id_num.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Pending Release
/fob?name=[name]	GET	Get individual Fob by name.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/fob?id=[id]	GET	Get individual Fob by system assigned id.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/fob	GET	List credentials tagged as FOBs.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/fob	POST	Create credentials tagged as FOBs.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/fob	PUT	Reassign credentials tagged as FOBs to a different user, and update expiration date.	Fob functions are specialized to handle and manipulate credential records that are specifically tagged for use as Fobs.	Released
/location	GET	Get list of locations.		Released
/location	POST	Create locations.		Released
/locationtype	GET	Get list of location types.		Released
/schedule	GET	List all schedules in the system.		Released
/unlock	POST	Momentary unlock of a wired door.		Released
/user	DELETE	Remove user records.		Released
/user	GET	List all non-administrative, card holder users in the system.		Released
/user?missingcreds	GET	List summary of users missing credentials.		Released
/user?privileged	GET	List users wiith privileged (application level) access.		Released
/user?installers	GET	List users with installer rights.		Released
/user?id=[id]	GET	Read individual non-administrative, card holder user with the specified id.	id represents the Lockt SecureAccess internal id.	Released
/user?id_num=[id_num]	GET	Read individual non-administrative, card holder user with the specified id_num.	id_num represents the user-supplied ID Number in Lockt SecureAccess.	Released
/user	POST	Bulk create new users.	Intended for use creating multiple User objects at once. Limited to maximum batch size per API account.	Released
/user	PUT	Selective user update.	Intended for updating individual user objects. Limits to one object per call.	Released

System Endpoints and Utilities

Endpoint	Method	Purpose	Status
/about	GET	Displays current release notes.	Released
/anonymize?user_id=[user_id]	POST	Anonymizes user data contained within user, audit, and event object archives.	Pending Release
/maintenance	GET	Displays scheduled maintenance details.	Released
/object?listtypes	GET	Displays available object types.	Released
/object?type=[type]	GET	Displays object information using the provided object type.	Released
/ping	GET	Simple ping response to check connectivity and authorization.	Released
/settings	GET	Retrieve api settings.	Released
/site	GET	Retrieve basic site information.	Released
/time	GET	Utility for working with times, timezones and offsets.	Released

The following validations are performed on the indicated method and object.

Endpoint	Method	Submethod	Field	Validation
accesslevel	POST		doors	Door ID is not duplicate
accesslevel	POST		doors	Schedule ID is valid
accesslevel	POST		name	Already exists in system
accesslevel	POST		name	Missing or blank
accesslevel	POST	id	doors	Door ID is valid
credential	DELETE		id	Id is not a Fob
credential	DELETE		id	Id is valid
credential	DELETE		id	Missing or blank
credential	DELETE		id	Non-Numeric
door	DELETE			Id is valid
door	DELETE		id	Missing or blank
door	GET		user_id	user_id is valid, numeric and not blank
door	POST		name	Already exists in system
door	POST		name	Missing or blank
fob	DELETE		id	Id is a Fob
fob	DELETE		id	Missing or blank
fob	DELETE		id	Non-Numeric
fob	POST		access_effective	Valid date format
fob	POST		access_expires	Valid date format
fob	POST		card_num	Already exists in system
fob	POST		card_num	Length versus system limit
fob	POST		card_num	Non-Numeric
fob	POST		id_num	Missing or blank
fob	POST		name	Already exists in system
fob	POST		name	Already exists in system
fob	POST		name	Missing or blank
fob	PUT		access_effective	Valid date format
fob	PUT		access_expires	Valid date format
fob	PUT		card_num	Already exists in system
fob	PUT		card_num	Length versus system limit
fob	PUT		card_num	Non-Numeric
fob	PUT		id_num	Missing or blank
fob	PUT		name	Already exists in system
fob	PUT		name	Already exists in system
fob	PUT		name	Missing or blank
location	POST		locationtype	Id is valid
location	POST		locationtype	Missing or blank
location	POST		name	Already exists in system
location	POST		name	Missing or blank
user	DELETE		id	Id is valid
user	DELETE		id	Missing or blank
user	DELETE		id	Non-Numeric
user	POST	INSERT	access_effective	Valid date format
user	POST	INSERT	access_expires	Valid date format
user	POST	INSERT	access_levels	Duplicate Assigned Access Levels
user	POST	INSERT	access_levels	Id is valid
user	POST	INSERT	card_num	Already exists in system
user	POST	INSERT	card_num	Length versus system limit
user	POST	INSERT	card_num	Non-Numeric
user	POST	INSERT	email	Already exists in system
user	POST	INSERT	email	Missing or blank
user	POST	INSERT	email	Proper email format
user	POST	INSERT	first_name	Missing or blank
user	POST	INSERT	id	Missing or blank
user	POST	INSERT	id	Non-Numeric
user	POST	INSERT	id_num	Already exists in system
user	POST	INSERT	id_num	Missing or blank
user	POST	INSERT	last_name	Missing or blank
user	POST	INSERT	phone	Missing or blank
user	POST	INSERT	phone	Proper phone format
user	POST	INSERT	pin	Length versus system limit
user	POST	INSERT	pin	Missing or blank
user	POST	INSERT	pin	Non-Numeric
user	POST	UPDATE	access_effective	Valid date format
user	POST	UPDATE	access_expires	Valid date format
user	POST	UPDATE	access_levels	Duplicate Assigned Access Levels
user	POST	UPDATE	access_levels	Id is valid
user	POST	UPDATE	card_num	Length versus system limit
user	POST	UPDATE	card_num	Non-Numeric
user	POST	UPDATE	card_num	Used for update determination
user	POST	UPDATE	email	Already exists in system
user	POST	UPDATE	email	Missing or blank
user	POST	UPDATE	email	Proper email format
user	POST	UPDATE	first_name	Missing or blank
user	POST	UPDATE	id	Missing or blank
user	POST	UPDATE	id	Non-Numeric
user	POST	UPDATE	id	Used for update determination
user	POST	UPDATE	id_num	Missing or blank
user	POST	UPDATE	id_num	Used for update determination
user	POST	UPDATE	last_name	Missing or blank
user	POST	UPDATE	phone	Missing or blank
user	POST	UPDATE	phone	Proper phone format
user	POST	UPDATE	pin	Length versus system limit
user	POST	UPDATE	pin	Missing or blank
user	POST	UPDATE	pin	Non-Numeric

The following endpoints are available for use. Details on request and response specifics can be found in the subsequent sections.

Endpoint	Method	Issue	Correction Plan
accesslevel	POST	Duplication check is spanning all supplied objects. Should be looking only within individual objects	Subsequent release
door	DELETE	valid door id's are sometimes considered to be invald	Subsequent release
door	POST	names are not checked for duplication within the batch	Subsequent release
user	GET	If querystring param id is supplied and is blank, full user result set is returned	Subsequent release
user	GET	If querystring param id_num is supplied and is blank, full user result set is returned	Subsequent release
user	POST	Duplicate PINs not validated on submit	Duplicate PIN enforcement will be removed by default in Lockt SecureAccess 2.5. This can be manually reset by Lockt in SecureAccess 2.4
various	VARIOUS	Dates can be returned in different formats depending on the endpoint. Dates supplied to POST or PUT operations will always be in the local time of the system. Dates read back from the system may come back in local time or in UTC. If the date returns in a format of YYYY-MM-DD HH:MM:SS it is returned in local time. If a date is returned in a format of YYYY-MM-DDTHH:MM:SSZ it is returned as UTC time.	Subsequent release

List

Purpose

List details of the current system release.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/about

Object Definition

Property	Data Type	Description
version	string	Current release version number.
release_date	string	Current release date.
release_notes	string	Overview of current release.
release_details	string	Additional details regarding the release.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/about"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": {
        "version": "1.1.0",
        "release_date": "Jul 10, 2022",
        "release_notes": "July 2022 Release - Enhancements, bug fixes, documentation updates",
        "release_details": "Correction of bugs in relay calls. \r\nExpanded validation of user supplied values across all endpoints.\r\nAddition of endpoints: /about, /maintenance, /location, /locationtype, /object, /user?missingcreds, /user?installers, /user?privileged\r\n \r\n"
    }
}

Purpose

List all access levels in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/accesslevel

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the access level.
name	string	The name of the access level.
doors	array	An array of abbreviated Door objects containing Door ID and Schedule ID only.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/accesslevel"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 208,
            "name": "Security",
            "doors": [
                {
                    "id": 983,
                    "name": "Office Door"
                },
                {
                    "id": 1087,
                    "name": "Front Door"
                }
            ]
        },
        {
            "id": 212,
            "name": "Administration"
        },
        {
            "id": 512,
            "name": "Cardholder"
        },
        {
            "id": 574,
            "name": "Housekeeping",
            "doors": [
                {
                    "id": 1087,
                    "name": "Front Door"
                }
            ]
        }
    ]
}

Purpose

List all access levels in the system by indicated name.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/accesslevel?name=name

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the access level.
name	string	The name of the access level.
doors	array	An array of abbreviated Door objects containing Door ID and Schedule ID only.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

name = 'Security'

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/accesslevel?name="+name

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 208,
            "name": "Security",
            "doors": [
                {
                    "id": 983,
                    "name": "Office Door"
                },
                {
                    "id": 1087,
                    "name": "Front Door"
                }
            ]
        }
    ]
}

Purpose

Creates access levels in the system using supplied door and schedule references.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/accesslevel

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
accesslevels	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "accesslevels": [array of access level objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
name	string	The name of the access level.
doors	array	An array of abbreviated Door objects containing Door ID and Schedule ID only.

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "accesslevels": [
    {
      "name": "Access Level l",
      "doors": [
        {
          "id": 12345,
          "schedule_id": 789
        }
      ]
    },
    {
      "name": "Access Level 2",
      "doors": [
        {
          "id": 23456,
          "schedule_id": 678
        }
      ]
    }
  ]
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/accesslevel'

accesslevelnode = {}
accessleveldata = [{} for i in range(2)]

doordata = [{} for i in range(1)]
doordata[0] = {'id': 12345, 'schedule_id': 789}
accessleveldata[0] = {'name':'Access Level 1', 'doors': doordata}

doordata = [{} for i in range(2)]
doordata[0] = {'id': 23456, 'schedule_id': 567}
doordata[1] = {'id': 12345, 'schedule_id': 789}
accessleveldata[1] = {'name':'Access Level 2', 'doors': doordata}

accesslevelnode['accesslevels'] = accessleveldata

accesslevelnode['options'] = {'validate_fails_batch':'true'}
doorjson = json.dumps(doornode)

r = requests.post(url, data=doorjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Purpose

Remove access levels from the system.

REST Method

DELETE

Request URL

https://cloudadpi.lockt.com/v1/accesslevel

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
accesslevels	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "accesslevels": [array of credential objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the access level

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "accesslevels": [
    {
        "id": 3456
    },
    {
        "id": 6578
    }
  ],
  "options": {
        "validate_fails_batch": "false"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/accesslevels'

acecsslevelnode = {}
acecssleveldata = [{} for i in range(2)]
acecssleveldata[0] = {'id':3456}
acecssleveldata[1] = {'id':6578}
acecsslevelnode['acecsslevels'] = acecssleveldata
acecsslevelnode['options'] = {'validate_fails_batch':'true'}
acecssleveljson = json.dumps(acecsslevelnode)

r = requests.delete(url, data=acecssleveljson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "deleted": number of records deleted,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 2,
        "errors": 0
    }
}

Purpose

List access levels used for delegation.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/delegate

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the delegate access level.
name	string	The name of the door
access_effective	timestamp	The date/time when access is enabled for this fob.
access_expires	timestamp	The date/time when access is disabled for this fob.
doors	array	An array of abbreviated Door objects containing Door ID and Name only.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/delegates"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 647929,
            "name": "delegate_af5abaf069caec3a33047702bfa6128a",
            "access_effective": "2022-09-08 11:00:00",
            "access_expires": "2022-09-08 12:00:00",
            "doors": [
                {
                    "id": 187,
                    "name": "Test Door"
                }
            ]
        },
        {
            "id": 647936,
            "name": "delegate_0f1fae3f0df3f2526aefddf814ef3056",
            "access_effective": "2022-09-08 11:00:00",
            "access_expires": "2022-09-08 12:00:00",
            "doors": [
                {
                    "id": 187,
                    "name": "Test Door"
                }
            ]
        }
    ]
}

Purpose

Delete all expired delegate access levels (where access_expires < current date/time).

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/delegate?purge

Behaviors

Context	Element	Behavior
PURGE	access_level	Access levels that are marked for delegation will be ignored if their access_expires date/time is still valid.
PURGE	access_level	All access levels where access_expires is before the current date/time will be deleted automatically.
PURGE	response	No objects are supplied in the response. Only a processing summary.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/delegates?purge"

r = requests.post(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 0,
        "errors": 0
    }
}

Purpose

Create and assign new delegate access.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/delegate

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
deelgates	An array of deelgate objects to be created.

Request Body Format

{
  "delegates": [array of delegate objects]
}

Object Definition

Property	Data Type	Description
from_user_id	integer	The user_id of the individual granting delegate access.
to_user_id	integer	The user_id of the individual receiving delegate access.
access_effective	date-time	The date/time when access is enabled for this delegate.
access_expires	date-time	The date/time when access is disabled for this delegate.
doors	array	An array of doors which the delegating user is assigning access to the receiving user.

Behaviors

Context	Element	Behavior
CREATE	doors	The system will only allow users to delegate doors to which they currently have access. Any doors that are granted via delegation are ignored.
CREATE	processing_options	No processing options are supplied for this endpoint. Errors will always result in batch failure.
CREATE	batch_size	This endpoint is limited to 1 object per call.

Example Request Body

{
    "delegates": [
        {
            "from_user_id": "613950",
            "to_user_id": "614111",
            "access_effective": "2022-09-07 22:20:00",
            "access_expires": "2022-09-07 22:53:00",
            "doors": [
                {"id": 187},
                {"id": 446}
            ]
        }
    ]
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/delegate'

delegatenode = {}
delegatedata = [{} for i in range(1)]
delegatedata[0] = {'from_user_id':613950,'to_user_id':614111,'access_effective':'2022-09-07 22:20:00','access_expires':'2022-09-07 22:53:00'}
doordata = [{} for i in range(2)]
doordata[0] = {'id':187}
doordata[1] = {'id':446}
delegatedata[0]['doors'] = doordata
delegatenode['delegates'] = delegatedata
delegatejson = json.dumps(delegatenode)
r = requests.post(url, data=delegatejson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response - Success

{
    "data": {
        "submitted": 1,
        "processed": 1,
        "errors": 0
    }
}

Example Response - Errors

{
    "result": [
        "Validation errors found. Batch has failed. Details provided."
    ],
    "errors": [
        {
            "error": [
                "Door id 1876 is not available to delegate",
                "Invalid access_effective date: 2022-09-07 12:00:00, must be before access_expires",
                "Invalid access_expires date: 2022-09-07 12:00:00, cannot be in past"
            ],
            "input_data": {
                "from_user_id": "613950",
                "to_user_id": "614111",
                "access_effective": "2022-09-08 11:00:00",
                "access_expires": "2022-09-07 12:00:00",
                "doors": [
                    {
                        "id": 1876
                    }
                ]
            }
        }
    ]
}

Purpose

List all credentials in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/credential

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the credential.
card_num	string	The card number assigned to the credential.
name	string	The name of the credential.
credential_key	string	The credential registration key assigned to the user.
claim_status	string	Indicates if credential is claimed.
user	object	Abbreviated object for the user to which the credential is assigned.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/credential"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 335,
            "card_num": "1003",
            "credential_key": "AAAA-BBBB-1111-2222",
            "claim_status": "Claimed",
            "user": [
                {
                    "id": 300,
                    "name": "User, Test"
                }
            ],
            "access_effective": "",
            "access_expires": ""
        },
        {
            "id": 129813,
            "card_num": "1234",
            "credential_key": "CCCC-DDDD-5555-6666",
            "claim_status": "Unclaimed",
            "user": [
                {
                    "id": 244,
                    "name": "Greswell, Rhea"
                }
            ],
            "access_effective": "",
            "access_expires": ""
        }
    ]
}

Purpose

List all credentials in the system, filtered by supplied user_id.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/credential?user_id=user_id

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the credential.
card_num	string	The card number assigned to the credential.
name	string	The name of the credential.
credential_key	string	The credential registration key assigned to the user.
claim_status	string	Indicates if credential is claimed.
user	object	Abbreviated object for the user to which the credential is assigned.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}

user_id = 12345

url = "https://cloudapi.lockt.com/api/v1/credential?user_id="+str(user_id)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 12345,
            "card_num": "8001",
            "credential_key": "AAAA-BBBB-1111-2222",
            "claim_status": "Claimed",
            "user": [
                {
                    "id": 300,
                    "name": "User, Test"
                }
            ],
            "access_effective": "",
            "access_expires": ""
        }
    ]
}

Purpose

List all credentials in the system, filtered by supplied card_num.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/credential?user_id=card_num

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the credential.
card_num	string	The card number assigned to the credential.
name	string	The name of the credential.
credential_key	string	The credential registration key assigned to the user.
claim_status	string	Indicates if credential is claimed.
user	object	Abbreviated object for the user to which the credential is assigned.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}

card_num = 8001

url = "https://cloudapi.lockt.com/api/v1/credential?card_num="+str(card_num)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 335,
            "card_num": "8001",
            "credential_key": "AAAA-BBBB-1111-2222",
            "claim_status": "Claimed",
            "user": [
                {
                    "id": 300,
                    "name": "User, Test"
                }
            ],
            "access_effective": "",
            "access_expires": ""
        }
    ]
}

Purpose

Remove credentials from the system.

REST Method

DELETE

Request URL

https://cloudadpi.lockt.com/v1/credential

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
credentials	An array of credential objects to be deleted.
options	Contains processing instructions for the operation.

Request Body Format

{
  "credentials": [array of credential objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the credential

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "credentials": [
    {
        "id": 237809
    },
    {
        "id": 236578
    }
  ],
  "options": {
        "validate_fails_batch": "false"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/credential'

credentialnode = {}
credentialdata = [{} for i in range(2)]
credentialdata[0] = {'id':237809}
credentialdata[1] = {'id':236578}
credentialnode['credentials'] = credentialdata
credentialnode['options'] = {'validate_fails_batch':'true'}
credentialjson = json.dumps(credentialnode)

r = requests.delete(url, data=credentialjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "deleted": number of records deleted,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 2,
        "errors": 0
    }
}

List

Purpose

Display summary of claimed and unclaimed credentials in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/credentialsummary

Object Definition

Property	Data Type	Description
credentials	integer	Total number of credentials issued in the system.
claimed	string	The number of credentials that have been claimed.
unclaimed	string	The number of credentials that have not been claimed.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/credentialsummary"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "credentials": 31,
            "claimed": 13,
            "unclaimed": 18
        }
    ]
}

Purpose

List all doors in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/door

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the door.
type	string	Text description of the door type
name	string	The name of the door
location	string	The location of the door.
enabled	boolean	Indicates whether the door is currently enabled or disabled.
controller	string	The name of the controller to which the door is attached.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/door"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 166,
            "type": "Access Controlled Door",
            "name": "Office Supplies",
            "location": "Main Hall",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 174,
            "type": "Access Controlled Door",
            "name": "Hall Entrance",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 603,
            "type": "Access Controlled Door",
            "name": "Maintenance Office",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        }
    ]
}

Purpose

List all doors assigned to the indicated user_id.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/door?user_id=user_id

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the door.
name	string	The name of the door

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
user_id = 12345
url = "https://cloudapi.lockt.com/api/v1/door?user_id=" + str(user_id)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 166,
            "type": "Access Controlled Door",
            "name": "Office Supplies",
            "location": "Main Hall",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 174,
            "type": "Access Controlled Door",
            "name": "Hall Entrance",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 603,
            "type": "Access Controlled Door",
            "name": "Maintenance Office",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        }
    ]
}

Purpose

List all doors assigned to the indicated id_num.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/door?id_num=id_num

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the door.
name	string	The name of the door

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
id_num = 'ZZ123'
url = "https://cloudapi.lockt.com/api/v1/door?id_num=" + id_num

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 166,
            "type": "Access Controlled Door",
            "name": "Office Supplies",
            "location": "Main Hall",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 174,
            "type": "Access Controlled Door",
            "name": "Hall Entrance",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        },
        {
            "id": 603,
            "type": "Access Controlled Door",
            "name": "Maintenance Office",
            "location": "",
            "enabled": true,
            "controller": "BEST Switch™ API"
        }
    ]
}

Purpose

Creates doors in the system. Specifically, creates Switch™Tech doors linked to the Switch™Tech controller.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/door

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
doors	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "doors": [array of door objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
name	text	The name of the door

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "doors": [
    {
        "name": "Door 1"
    },
    {
        "name": "Door 2"
    }
  ],
  "options": {
        "validate_fails_batch": "false"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/door'

doornode = {}
doordata = [{} for i in range(2)]
doordata[0] = {'name':'Door 1'}
doordata[1] = {'name':'Door 2'}
doornode['doors'] = doordata
doornode['options'] = {'validate_fails_batch':'true'}
doorjson = json.dumps(doornode)

r = requests.post(url, data=doorjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response - Success

{
    "data": {
        "submitted": 1,
        "inserted": 1,
        "updated": 1,
        "errors": 0
    }
}

Example Response - Errors

{
    "result": [
        "Validation errors found. Batch has failed. Details provided."
    ],
    "errors": [
        {
            "error": [
                "Door Name Already Exists: Door 1"
            ],
            "input_data": {
                "name": "Door 1"
            }
        }
    ]
}

Purpose

Remove doors from the system.

REST Method

DELETE

Request URL

https://cloudadpi.lockt.com/v1/door

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
doors	An array of door objects to be deleted.
options	Contains processing instructions for the operation.

Request Body Format

{
  "doors": [array of door objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique system assigned id of the door.

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "doors": [
    {
      "id": 32871
    },
    {
      "id": 45612
    }
  ],
    "options": {
        "validate_fails_batch": "true"
    }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/door'

doornode = {}
doordata = [{} for i in range(2)]
doordata[0] = {'id':32871}
doordata[1] = {'id':45612}
doornode['doors'] = doordata
doornode['options'] = {'validate_fails_batch':'true'}
doorjson = json.dumps(doornode)

r = requests.delete(url, data=doorjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "deleted": number of records deleted,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 2,
        "errors": 0
    }
}

List All

Purpose

List all doors states in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/doorstate

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the door.
name	string	The name of the door
battery_level	decimal	The battery level of the door expressed as a decimal, if applicable.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/doorstate"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 187,
            "name": "Room 1",
            "battery_level": 0.64
        },
        {
            "id": 446,
            "name": "Room 2",
            "battery_level": 0.74
        },
        {
            "id": 611127,
            "name": "Room 3",
            "battery_level": 0.99
        }
    ]
}

List All
Read after id

Purpose

Read all available events, up to a maximum of 5000 records.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/events

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the event
device	string	The name device causing the event
code	integer	The integer representation of the event code
code_text	string	The text rerpresentation of the event code
subcode	integer	The integer representation of the event sub-code
subcode_text	string	The text rerpresentation of the event sub-code
schedule	string	The name of the schedule, if applicable
controller	string	The name of the controller, if applicable
location	string	The name of the location where the device is assigned, if applicable
card_num	string	The card number assigned to the user
user	string	The name of the user
category	integer	The integer representation of the event category
category_text	string	The text representation of the event category
event_time	date-time	The event timestamp received from the device
db_time	date-time	The timestamp when the event was recorded in the system

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/events"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 865,
            "device": "Core 1",
            "code": 49,
            "code_text": "Access Denied",
            "subcode": 104,
            "subcode_text": "Battery Missing",
            "schedule": "",
            "controller": "Switch™ Bridge",
            "location": "Main Hall",
            "card_num": "1000",
            "user": "Jones, Adam",
            "category": 2,
            "category_text": "Door Access Denied",
            "hw_time": "2021-11-18T16:15:28.000Z",
            "db_time": "2021-11-19T00:47:09.651Z"
        },
        {
            "id": 864,
            "device": "Core 1",
            "code": 49,
            "code_text": "Access Denied",
            "subcode": 104,
            "subcode_text": "Battery Missing",
            "schedule": "",
            "controller": "Switch™ Bridge",
            "location": "Main Hall",
            "card_num": "1000",
            "user": "Smith, Sally",
            "category": 2,
            "category_text": "Door Access Denied",
            "hw_time": "2021-11-18T16:15:25.000Z",
            "db_time": "2021-11-19T00:44:06.950Z"
        },
        {
            "id": 837,
            "device": "Core 2",
            "code": 48,
            "code_text": "Access Granted",
            "schedule": "",
            "controller": "Switch™ Bridge",
            "location": "",
            "card_num": "1001",
            "user": "Jackson, Kelly",
            "category": 1,
            "category_text": "Door Access Granted",
            "hw_time": "2021-11-17T13:58:01.000Z",
            "db_time": "2021-11-17T13:58:07.035Z"
        }
    ]
}

Purpose

Retrieve a list of event objects after the specified id.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/events?id=id

Request Parameters

Name	Description	Data Type	Optional / Required
id	A numeric id representing the unique record identifier in Lockt SecureAccess	integer	required

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the event
device	string	The name device causing the event
code	integer	The integer representation of the event code
code_text	string	The text rerpresentation of the event code
subcode	integer	The integer representation of the event sub-code
subcode_text	string	The text rerpresentation of the event sub-code
schedule	string	The name of the schedule, if applicable
controller	string	The name of the controller, if applicable
location	string	The name of the location where the device is assigned, if applicable
card_num	string	The card number assigned to the user
user	string	The name of the user
category	integer	The integer representation of the event category
category_text	string	The text representation of the event category
event_time	date-time	The event timestamp received from the device
db_time	date-time	The timestamp when the event was recorded in the system

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
lastid = 17249

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/events?id=" + str(lastid)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 865,
            "device": "Core 1",
            "code": 49,
            "code_text": "Access Denied",
            "subcode": 104,
            "subcode_text": "Battery Missing",
            "schedule": "",
            "controller": "Switch™ Bridge",
            "location": "Main Hall",
            "card_num": "1000",
            "user": "Jones, Adam",
            "category": 2,
            "category_text": "Door Access Denied",
            "hw_time": "2021-11-18T16:15:28.000Z",
            "db_time": "2021-11-19T00:47:09.651Z"
        },
        {
            "id": 864,
            "device": "Core 1",
            "code": 49,
            "code_text": "Access Denied",
            "subcode": 104,
            "subcode_text": "Battery Missing",
            "schedule": "",
            "controller": "Switch™ Bridge",
            "location": "Main Hall",
            "card_num": "1000",
            "user": "Smith, Sally",
            "category": 2,
            "category_text": "Door Access Denied",
            "hw_time": "2021-11-18T16:15:25.000Z",
            "db_time": "2021-11-19T00:44:06.950Z"
        }
    ]
}

Purpose

List all fobs in the system. Fobs are credential objects that are specifically tagged to be used as Fobs.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/fob

Object Definition

Property	Data Type	Description
id_num	text	Unique id number to identify the fob. Supplied by external system.
name	string	The name of the fob.
card_num	string	The card number assigned to the fob.
credential_key	string	The credential registration key assigned to the fob.
enabled	boolean	Indicates whether the fob is enabled.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.
accesslevels	array	An array of access level assignment objects associated with this fobs.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/fob"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 443,
            "id_num": "10000",
            "name": "Office Floor 1 FOB 1",
            "card_num": "10000",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "enabled": false,
            "access_effective": "2022-07-10T09:00:00.000Z",
            "access_expires": "2022-07-10T12:00:00.000Z",
            "accesslevels": []
        },
        {
            "id": 232,
            "id_num": "10000",
            "name": "Office Floor 2 FOB 1",
            "card_num": "11000",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "enabled": false,
            "access_effective": "2022-07-10T09:00:00.000Z",
            "access_expires": "2022-07-10T12:00:00.000Z",
            "accesslevels": []
        }
  ]
}

Purpose

Read specific Fob record by indicated id.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/fob?id=id

Object Definition

Property	Data Type	Description
id_num	text	Unique id number to identify the fob. Supplied by external system.
name	string	The name of the fob.
card_num	string	The card number assigned to the fob.
credential_key	string	The credential registration key assigned to the fob.
enabled	boolean	Indicates whether the fob is enabled.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.
accesslevels	array	An array of access level assignment objects associated with this fobs.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
id = 443
url = "https://cloudapi.lockt.com/api/v1/fob?id="+str(id)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 443,
            "id_num": "10000",
            "name": "Office Floor 1 FOB 1",
            "card_num": "10000",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "enabled": false,
            "access_effective": "2022-07-10T09:00:00.000Z",
            "access_expires": "2022-07-10T12:00:00.000Z",
            "accesslevels": []
        }
  ]
}

Purpose

Read specific Fob record by indicated id_num.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/fob?id_num=id_num

Object Definition

Property	Data Type	Description
id_num	text	Unique id number to identify the fob. Supplied by external system.
name	string	The name of the fob.
card_num	string	The card number assigned to the fob.
credential_key	string	The credential registration key assigned to the fob.
enabled	boolean	Indicates whether the fob is enabled.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.
accesslevels	array	An array of access level assignment objects associated with this fobs.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
id_num = "10000"
url = "https://cloudapi.lockt.com/api/v1/fob?id_num="+str(id_num)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 443,
            "id_num": "10000",
            "name": "Office Floor 1 FOB 1",
            "card_num": "10000",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "enabled": false,
            "access_effective": "2022-07-10T09:00:00.000Z",
            "access_expires": "2022-07-10T12:00:00.000Z",
            "accesslevels": []
        }
  ]
}

Purpose

Read specific Fob record by indicated card_num.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/fob?card_num=card_num

Object Definition

Property	Data Type	Description
id_num	text	Unique id number to identify the fob. Supplied by external system.
name	string	The name of the fob.
card_num	string	The card number assigned to the fob.
credential_key	string	The credential registration key assigned to the fob.
enabled	boolean	Indicates whether the fob is enabled.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.
accesslevels	array	An array of access level assignment objects associated with this fobs.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
card_num = "10000"
url = "https://cloudapi.lockt.com/api/v1/fob?card_num="+str(card_num)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 443,
            "id_num": "10000",
            "name": "Office Floor 1 FOB 1",
            "card_num": "10000",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "enabled": false,
            "access_effective": "2022-07-10T09:00:00.000Z",
            "access_expires": "2022-07-10T12:00:00.000Z",
            "accesslevels": []
        }
  ]
}

Purpose

Creates new Fob records. Fobs are credential objects that are specifically tagged to be used as Fobs.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/fob

Request Body Format

{
  "fobs": [array of fob objects]
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the fob
id_num	string	Unique id number to identify the fob. Supplied by external system.
name	string	The name of the fob.
card_num	string	The card number assigned to the fob.
access_effective	date-time	The date/time when access is enabled for this fob.
access_expires	date-time	The date/time when access is disabled for this fob.

Example Request Body

{
   "fobs": [
   {
    "name": "Fob 1",
    "id_num": "ABC123",
    "card_num": 5599,
    "access_effective": "2022-05-05 05:00:00",
    "access_expires": "2022-05-25 08:00:00"
   }
  ]
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/fob'

fobnode = {}
fobdata = [{} for i in range(1)]
fobdata[0] = {'name':'Fob 1','id_num':'ABC123','card_num':'5599','access_effective':'','access_expires':''}
fobnode['fobs'] = fobdata
fobjson = json.dumps(fobnode)

r = requests.post(url, data=fobjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "inserted": number of records inserted,
        "updated": number of records updated,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 1,
        "inserted": 1,
        "updated": 0,
        "errors": 0
    }
}

Purpose

Reassigns a Fob to an indicated User record, thereby inheriting access rights. Fobs are credential objects that are specifically tagged to be used as Fobs.

REST Method

PUT

Request URL

https://cloudapi.lockt.com/api/v1/fob

Request Body Format

{
  "fobs": [array of fob objects]
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the fob
user_id	string	The unique, system assigned id of the user record to which tis fob will be assigned
access_effective	timestamp	The date/time when access is enabled for this fob.
access_expires	timestamp	The date/time when access is disabled for this fob.

Behaviors

Context	Element	Behavior
REASSIGN	user_id	If 0 is supplied, the system will take this as a signal to remove any existing user assignments from this FOB.

Example Request Body

{
   "fobs": [
   {
    "id": "613297",
    "user_id": "613188",
    "access_effective": "2022-06-10 05:00:00",
    "access_expires": "2022-06-10 08:00:00"
   }
  ]
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/fob'

fobnode = {}
fobdata = [{} for i in range(1)]
fobdata[0] = {'id':12345,'user_id':87654}
fobnode['fobs'] = fobdata
fobjson = json.dumps(fobnode)

r = requests.put(url, data=fobjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "inserted": number of records inserted,
        "updated": number of records updated,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 1,
        "inserted": 1,
        "updated": 0,
        "errors": 0
    }
}

Purpose

Remove Fobs from the system.

REST Method

DELETE

Request URL

https://cloudadpi.lockt.com/v1/fob

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
locations	An array of location objects to be deleted.
options	Contains processing instructions for the operation.

Request Body Format

{
  "fobs": [array of fob objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique system assigned id of the location.

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "fobs": [
    {
      "id": 7134
    },
    {
      "id": 6398
    }
  ],
    "options": {
        "validate_fails_batch": "true"
    }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/fob'

locationnode = {}
locationdata = [{} for i in range(2)]
locationdata[0] = {'id':7134}
locationdata[1] = {'id':6398}
locationnode['locations'] = locationdata
locationnode['options'] = {'validate_fails_batch':'true'}
locationjson = json.dumps(locationnode)

r = requests.delete(url, data=locationjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "deleted": number of records deleted,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 2,
        "errors": 0
    }
}

List All
Create

Purpose

List all locations in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/location

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the location.
name	string	The name of the location
type	string	The type of the location.
enabled	boolean	Indicates whether the location is currently enabled or disabled.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/location"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 123456,
            "name": "North Region",
            "type": "Region",
            "enabled": false
        },
        {
            "id": 123457,
            "name": "Headquarters",
            "type": "Campus",
            "enabled": false
        },
        {
            "id": 123458,
            "name": "University",
            "type": "Campus",
            "enabled": false
        }
    ]
}

Purpose

Creates locations in the system.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/location

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
locations	An array of location objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "locations": [array of location objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
name	string	The name of the location.
locationtype	integer	Reference to the id of the location type for this location

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "locations": [
    {
      "name": "Main Campus",
      "locationtype": 175
    },
    {
      "name": "Back Warehouse",
      "locationtype": 192
    }
  ],
    "options": {
        "validate_fails_batch": "true"
    }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/location'

locationnode = {}
locationdata = [{} for i in range(2)]
locationdata[0] = {'name':'Main Campus','locationtype': 175}
locationdata[1] = {'name':'Back Warehouse', 'locationtype': 192}
locationnode['locations'] = locationdata

locationnode['options'] = {'validate_fails_batch':'true'}
doorjson = json.dumps(doornode)

r = requests.post(url, data=doorjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

List All

Purpose

List all location types in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/locationtype

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the location type.
name	string	The name of the location type

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/locationtype"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 23981,
            "name": "Building"
        },
        {
            "id": 1345,
            "name": "Floor"
        }
    ]
}

List Types
Get Object

Purpose

List all objects in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/object?listtypes

Object Definition

Property	Data Type	Description
object	string	Name of the object.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/object?listtypes"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "object": "accesslevel"
        },
        {
            "object": "accesslevel_create"
        },
        {
            "object": "credential"
        },
        {
            "object": "door"
        },
        {
            "object": "door_create"
        },
        {
            "object": "doorstate"
        },
        {
            "object": "event"
        },
        {
            "object": "fob"
        },
        {
            "object": "location"
        },
        {
            "object": "locationtype"
        },
        {
            "object": "maintenance"
        },
        {
            "object": "schedule"
        },
        {
            "object": "user"
        },
        {
            "object": "user_create"
        },
        {
            "object": "user_delete"
        }
    ]
}

Purpose

Get object by type.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/object?type=type

Object Definition

Property	Data Type	Description
property	string	Property name of the object.
datatype	string	Pata type of the property.
description	string	Description of the property

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/object?type=location"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "property": "id",
            "datatype": "integer",
            "description": "The unique, system assigned id of the location."
        },
        {
            "property": "name",
            "datatype": "string",
            "description": "The name of the location"
        },
        {
            "property": "type",
            "datatype": "string",
            "description": "The type of the location."
        },
        {
            "property": "enabled",
            "datatype": "boolean",
            "description": "Indicates whether the location is currently enabled or disabled."
        }
    ]
}

List All

Purpose

List all schedules in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/schedule

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the schedule.
name	string	The name of the schedule.
d0	bit	Will be set to 1 if the schedule includes day 0 (typically Monday).
d1	bit	Will be set to 1 if the schedule includes day 1 (typically Tuesday).
d2	bit	Will be set to 1 if the schedule includes day 2 (typically Wednesday).
d3	bit	Will be set to 1 if the schedule includes day 3 (typically Thursday).
d4	bit	Will be set to 1 if the schedule includes day 4 (typically Friday).
d5	bit	Will be set to 1 if the schedule includes day 5 (typically Saturday).
d6	bit	Will be set to 1 if the schedule includes day 6 (typically Sunday).
start	time	The time the schedule starts in format HH:MM:SS
stop	time	The time the schedule stops in format HH:MM:SS

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/schedule"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 543,
            "name": "0800-1700 M-F, 1200-1500 Sat",
            "d0": 1,
            "d1": 1,
            "d2": 1,
            "d3": 1,
            "d4": 1,
            "d5": 0,
            "d6": 0,
            "start": "08:00:00",
            "stop": "16:59:59"
        },
        {
            "id": 1404,
            "name": "Weekend Cleaners",
            "d0": 0,
            "d1": 0,
            "d2": 0,
            "d3": 0,
            "d4": 0,
            "d5": 1,
            "d6": 1,
            "start": "06:40:00",
            "stop": "19:49:59"
        }
    ]
}

Purpose

List all non-administrative, card holder users in the system.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 5678,
            "id_num": "",
            "name": "Fob 1",
            "card_num": "10000",
            "credential_key": "",
            "enabled": false,
            "access_effective": "",
            "access_expires": "",
            "accesslevels": []
        },
        {
            "id": 6789,
            "id_num": "",
            "name": "Fob 2",
            "card_num": "10001",
            "credential_key": "",
            "enabled": false,
            "access_effective": "2022-05-05T09:00:00.000Z",
            "access_expires": "2022-05-05T12:00:00.000Z",
            "accesslevels": []
        }
    ]
}

Purpose

Read individual non-administrative, card holder user with the specified id.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user?id=id

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.
credentials	array	An array of credential objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
id = 1693

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user?id=" + str(id)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 1693,
            "id_num": "329359",
            "last_name": "Brown3",
            "first_name": "Susan3",
            "card_num": "8769",
            "pin": "8822",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "email": "susan.brown@web.place",
            "phone": "33344455555",
            "access_effective": "",
            "access_expires": "",
            "enabled": true,
            "accesslevels": [
                {
                    "unid": 364,
                    "name": "Office Doors"
                }
            ],
            "credentials": [
                {
                    "id": 613832,
                    "name": "8769",
                    "card_num": "8769",
                    "credential_key": "XXXX-XXXX-XXXX-XXXX",
                    "fob": false
                },
                {
                    "id": 614010,
                    "name": "Fob 1A",
                    "card_num": "10050",
                    "credential_key": "YYYY-YYYY-YYYY-YYYY",
                    "fob": true
                }
            ]
        }
    ]
}

Purpose

Read individual non-administrative, card holder user with the specified idnum.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user?id_num=id_num

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.
credentials	array	An array of credential objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
idnum = "ABC123-98765"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user?idnum=" + str(idnum)

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 1693,
            "id_num": "329359",
            "last_name": "Brown3",
            "first_name": "Susan3",
            "card_num": "8769",
            "pin": "8822",
            "credential_key": "XXXX-XXXX-XXXX-XXXX",
            "email": "susan.brown@web.place",
            "phone": "33344455555",
            "access_effective": "",
            "access_expires": "",
            "enabled": true,
            "accesslevels": [
                {
                    "unid": 364,
                    "name": "Office Doors"
                }
            ],
            "credentials": [
                {
                    "id": 613832,
                    "name": "8769",
                    "card_num": "8769",
                    "credential_key": "XXXX-XXXX-XXXX-XXXX",
                    "fob": false
                },
                {
                    "id": 614010,
                    "name": "Fob 1A",
                    "card_num": "10050",
                    "credential_key": "YYYY-YYYY-YYYY-YYYY",
                    "fob": true
                }
            ]
        }
    ]
}

Purpose

List all non-administrative, card holder users in the system that are missing credentials.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user?missingcreds

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
id = 1693

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user?missingcreds

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 5678,
            "id_num": "",
            "name": "Fob 1",
            "card_num": "10000",
            "credential_key": "",
            "enabled": false,
            "access_effective": "",
            "access_expires": "",
            "accesslevels": []
        },
        {
            "id": 6789,
            "id_num": "",
            "name": "Fob 2",
            "card_num": "10001",
            "credential_key": "",
            "enabled": false,
            "access_effective": "2022-05-05T09:00:00.000Z",
            "access_expires": "2022-05-05T12:00:00.000Z",
            "accesslevels": []
        }
    ]
}

Purpose

List all users with installer rights.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user?installers

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
id = 1693

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user?installers

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 5678,
            "id_num": "",
            "name": "Fob 1",
            "card_num": "10000",
            "credential_key": "",
            "enabled": false,
            "access_effective": "",
            "access_expires": "",
            "accesslevels": []
        },
        {
            "id": 6789,
            "id_num": "",
            "name": "Fob 2",
            "card_num": "10001",
            "credential_key": "",
            "enabled": false,
            "access_effective": "2022-05-05T09:00:00.000Z",
            "access_expires": "2022-05-05T12:00:00.000Z",
            "accesslevels": []
        }
    ]
}

Purpose

List all privileged users (with access to the system).

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/user?privileged

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
credential_key	string	The credential registration key assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
accesslevels	array	An array of access level assignment objects associated with this user.

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"
id = 1693

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/user?privileged

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "id": 5678,
            "id_num": "",
            "name": "Fob 1",
            "card_num": "10000",
            "credential_key": "",
            "enabled": false,
            "access_effective": "",
            "access_expires": "",
            "accesslevels": []
        },
        {
            "id": 6789,
            "id_num": "",
            "name": "Fob 2",
            "card_num": "10001",
            "credential_key": "",
            "enabled": false,
            "access_effective": "2022-05-05T09:00:00.000Z",
            "access_expires": "2022-05-05T12:00:00.000Z",
            "accesslevels": []
        }
    ]
}

Purpose

Create/update users in the system.

REST Method

POST

Request URL

https://cloudadpi.lockt.com/v1/user/

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
users	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "users": [array of user objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
id_num	string	Unique id number to identify the user. Supplied by external system.
first_name	string	The first name of the user.
last_name	string	The last name of the user.
card_num	string	The card number assigned to the user.
email	string	The email address associated with the user.
phone	string	The phone number associated with the user.
pin	integer	The pin number associated with the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
enabled	boolean	Flag to enable / disable the user.
accesslevels	array	An array of access level assignment objects associated with this users.

Access Level Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the access level.

Behaviors

Context	Element	Behavior
INSERT	id	On initial insert, this value must be -1.
INSERT/UPDATE	id, id_num, email	A valid id is required for the system to consider an update. Once an update is determined, it will check the id_num and email for validity. Note: Previously, the system would consider any match of these fields to be a trigger for update. This has been updated as the previous method could result in inconsistent matches.
UPDATE	card_num	If a value of -1 is supplied, the system will consider that as an signal to remove all existing, non-FOB credentials from the user.
INSERT/UPDATE	card_num	A supplied card_num will be used only if the record is 1) being inserted, 2) has no existing card, 3) value is -1 (see above). Otherwise, card_num will be ignored during updates.
UPDATE	access_levels	If access_levels are provided, and replace_privileges=false, the system will consider that as the access_levels being addative to the current access_level set.
UPDATE	access_levels	If access_levels are provided, and replace_privileges=true, the system will consider that as signal to replace the users current access_levels with the supplied values.
UPDATE	access_levels	If access_levels are provided as an empty object, and replace_privileges=true, the system will consider that as signal to remove all existing access_levels from the user.
UPDATE	update_existing	If update_existing=false, records that are determined to be updates of existing records will be ignored.
UPDATE	validate_fails_batch	If validate_fails_batch=false, and validation errors are found, records not containing errors will be processed.

Processing Options Object Definition

Property	Data Type	Description
update_existing	boolean	If set to false, any user objects submitted with a matching id_num or email address will be ignored. If set to true, the system will attempt to update existing records by matching id_num and email address. This property defaults to false if not presented.
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.
replace_privileges	boolean	If set to false, privileges will be added to the user's existing privileges. If set to true, the existing privileges will be deleted and the new privileges added. This property defaults to true if not presented.

Example Request Body

{
  "users": [
    {
        "id": 4432,
        "id_num": "ABC123",
        "last_name": "Peters",
        "first_name": "Toby",
        "card_num": "8769",
        "credential_key": "",
        "email": "toby.peters@web.place",
        "pin": "1234",
        "phone": "33344455555",
        "access_effective": "",
        "access_expires": "",
        "enabled": "true",
        "accesslevels": [
                {"id": 123},
                {"id": 789}
        ]
    },
    {
        "id": 7612,
        "id_num": "DEF567",
        "last_name": "Wilson",
        "first_name": "Dana",
        "card_num": "8769",
        "credential_key": "",
        "email": "dana.wilson@web.place",
        "pin": "4567",
        "phone": "33344455555",
        "access_effective": "",
        "access_expires": "",
        "enabled": "true",
        "accesslevels": [
                {"id": 123},
                {"id": 789}
        ]
    }
  ],
  "options": {
        "update_existing": "true",
        "validate_fails_batch": "false",
        "replace_privileges": "true"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/user'

usernode = {}
userdata = [{} for i in range(2)]
userdata[0] = {'id':4432,'id_num':'ABC123','last_name':'Peters','first_name':'Toby','card_num':'5588','credential_key':'','email':'toby.peters@web.place','phone':'33344455555','access_effective':'','access_expires':'','enabled':'true'}
userdata[1] = {'id':7612,'id_num':'DEF567','last_name':'Wilson','first_name':'Dana','card_num':'9900','credential_key':'','email':'dana.wilson@web.place','phone':'33344455555','access_effective':'','access_expires':'','enabled':'true'}
usernode['users'] = userdata
usernode['options'] = {'update_existing':'true','validate_fails_batch':'true','replace_privileges':'true'}
userjson = json.dumps(usernode)

r = requests.post(url, data=userjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "inserted": number of records inserted,
        "updated": number of records updated,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 1,
        "inserted": 0,
        "updated": 1,
        "errors": 0
    }
}

Purpose

Update users individually.

REST Method

PUT

Request URL

https://cloudadpi.lockt.com/v1/user/

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
users	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "users": [array of user objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user
card_num	string	The card number assigned to the user.
access_effective	date-time	The date/time when access is enabled for this user.
access_expires	date-time	The date/time when access is disabled for this user.
enabled	boolean	Flag to enable / disable the user.
accesslevels	array	An array of access level assignment objects associated with this users.

Access Level Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the access level.

Behaviors

Context	Element	Behavior
UPDATE	id	Required.
UPDATE	card_num	If a value of -1 is supplied, the system will consider that as an signal to remove all existing, non-FOB credentials from the user.
UPDATE	card_num	A supplied card_num will be used only if the record 1) has no existing card, 2) value is -1 (see above). Otherwise, card_num will be ignored during updates.
UPDATE	access_levels	If access_levels are provided, and replace_privileges=false, the system will consider that as the access_levels being addative to the current access_level set.
UPDATE	access_levels	If access_levels are provided, and replace_privileges=true, the system will consider that as signal to replace the users current access_levels with the supplied values.
UPDATE	access_levels	If access_levels are provided as an empty object, and replace_privileges=true, the system will consider that as signal to remove all existing access_levels from the user.
UPDATE	access_effective / access_expires	access_effective must be before access_expires. access_expires cannot be in the past.
UPDATE	all	All properties but id are optional. The system will act upon only the supplied object properties.

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.
replace_privileges	boolean	If set to false, privileges will be added to the user's existing privileges. If set to true, the existing privileges will be deleted and the new privileges added. This property defaults to true if not presented.

Example Request Body

## Full Object
{
    "users": [
    {
        "id": "618395",
        "enabled": true,
        "access_effective": "",
        "access_expires": "2022-09-20 08:00:00",
        "card_num": "123456",
        "accesslevels": [{"id":188}]
    }
], "options": {
        "validate_fails_batch": "true",
        "replace_privileges": "true"
  }
}

## Selective Update Example 1
##
## The system will process only the supplied values
##
{
    "users": [
    {
        "id": "618395",
        "card_num": "123456"
    }
], "options": {
        "validate_fails_batch": "true",
        "replace_privileges": "true"
  }
}

## Selective Update Example 2
##
## The system will process only the supplied values
##
{
    "users": [
    {
        "id": "618395",
        "accesslevels": [{"id":188}]
    }
], "options": {
        "validate_fails_batch": "true",
        "replace_privileges": "true"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/user'

usernode = {}
userdata = [{} for i in range(2)]
userdata[0] = {'id':4432,'card_num':'5588'}
usernode['users'] = userdata
usernode['options'] = {'validate_fails_batch':'true','replace_privileges':'true'}
userjson = json.dumps(usernode)

r = requests.put(url, data=userjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
  "users": [array of user objects],
  "options": {processing options}
}

Example Response

{
    "data": {
        "submitted": 1,
        "inserted": 0,
        "updated": 1,
        "errors": 0
    }
}

Purpose

Delete users from the system.

REST Method

DELETE

Request URL

https://cloudadpi.lockt.com/v1/user/

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
users	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "users": [array of user objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the user

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "users": [
    {
        "id": 4432
    },
    {
        "id": 7612
    }
  ],
  "options": {
        "validate_fails_batch": "false"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/user'

usernode = {}
userdata = [{} for i in range(2)]
userdata[0] = {'id':4432}
userdata[1] = {'id':7612}
usernode['users'] = userdata
usernode['options'] = {'validate_fails_batch':'true'}
userjson = json.dumps(usernode)

r = requests.delete(url, data=userjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Response Body Format

{
    "data": {
        "submitted": number of records submitted,
        "deleted": number of records deleted,
        "errors": number of errors encountered
    }
}

Example Response

{
    "data": {
        "submitted": 2,
        "deleted": 2,
        "errors": 0
    }
}

Time

Purpose

Returns current time, timezone, and time offset information for use in handling dates.

REST Method

GET

Request URL

https://cloudapi.lockt.com/api/v1/time

Code Examples

Python

import json
import requests

apiuser = "9r8ehveyb5h8mnwwet4yf9ugjynz8pkn"
apikey =  "hqx7wde64vwe987fvg6q4zaautrs3p7j"

headers = {"Content-type": "application/json", "apiuser":apiuser ,"apikey":apikey}
url = "https://cloudapi.lockt.com/api/v1/fob"

r = requests.get(url, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response

{
    "data": [
        {
            "datetime_utc": "2022-11-11T20:17:45.050Z",
            "timezone": "America/New_York",
            "datetime_local": "2022-11-11 15:17:45",
            "offset": -5
        }
    ]
}

Momentary Unlock

Purpose

Momentary unlock of wired door.

REST Method

POST

Request URL

https://cloudapi.lockt.com/api/v1/unlock

Request Body Parameters

The body of the operation contains the following nodes:

Node	Description
doors	An array of user objects to be created.
options	Contains processing instructions for the operation.

Request Body Format

{
  "doors": [array of door objects],
  "options": {processing options}
}

Object Definition

Property	Data Type	Description
id	integer	The unique, system assigned id of the door

Processing Options Object Definition

Property	Data Type	Description
validate_fails_batch	boolean	If set to false, validation errors will be returned in the response body and records passing validation will be processed. If set to true, a validation error will fail the entire batch. This property defaults to true if not presented.

Example Request Body

{
  "doors": [
    {
        "name": "Door 1"
    },
    {
        "name": "Door 2"
    }
  ],
  "options": {
        "validate_fails_batch": "false"
  }
}

Code Examples

Python

import json
import requests

apiuser = '9r8ehveyb5h8mnwwet4yf9ugjynz8pkn'
apikey =  'hqx7wde64vwe987fvg6q4zaautrs3p7j'

headers = {'Content-type': 'application/json', 'apiuser':apiuser ,'apikey':apikey}
url = 'https://cloudapi.lockt.com/api/v1/unlock'

doornode = {}
doordata = [{} for i in range(1)]
doordata[0] = {'id':12345}
doornode['doors'] = doordata
doornode['options'] = {'validate_fails_batch':'true'}
doorjson = json.dumps(doornode)

r = requests.post(url, data=doorjson, headers=headers)
data = r.json()
if r.status_code == 200:
    #process the response
else:
    #check for failed response

Example Response - Success

{
    "data": [
        {
            "id": 12345,
            "name": "Wired Door 1",
            "unlocked": true,
            "status": "unlocked",
            "errors": []
        }
    ]
}

Example Response - Errors

{
    "data": [
        {
            "id": 12345,
            "name": "Wired Door 1",
            "unlocked": false,
            "status": "error",
            "errors": [
                "Unexpected error unlocking door. Door or Controller may be offline."
            ]
        }
    ]
}

Cloud API Reference

General Overview

Release Notes

Release 1.1.0

Release Details

Change Log

Changes

Requests, Authentication, and Response Codes

HTTPS

URL

API Versions

Authentication

Authentication Header Example

Content-Type

Response Codes

Expected Outputs

Restrictions

Standard Response Format

GET Requests (Read)

Response Format

POST Requests (Write)

Response Format

Object Relationships and Descriptions

Entity Model

Domain Model

Relationships

Endpoints

Functional Endpoints

System Endpoints and Utilities

Validations

Known Issues

About

Purpose

REST Method

Request URL

Object Definition

Code Examples

Example Response

Access Levels

Purpose

REST Method

Request URL

Object Definition

Code Examples

Example Response

Purpose

REST Method

Request URL

Object Definition

Code Examples

Example Response

Purpose

REST Method

Request URL

Request Body Parameters

Request Body Format

Object Definition

Processing Options Object Definition

Example Request Body

Code Examples

Purpose

REST Method

Request URL

Request Body Parameters

Request Body Format

Object Definition

Processing Options Object Definition

Example Request Body

Code Examples

Response Body Format

Example Response

Access Delegation

Purpose

REST Method

Request URL

Object Definition

Code Examples

Example Response

Purpose

REST Method
